Modular hot stamping machine for high precision hot stamping of cylindrical, angled, non-circular and conical parts like mascara, sleeves, liners, etc. as well as heat transfer applications.
The DecoFlex F was developed to meet the special and complex requirements of decorating mascara bottles and caps. The machine allows the most varied shapes of bottles and caps to be decorated by hot stamping. The DecoFlex F is the only machine that can decorate cylindrical, square, oval, and conical parts without having to retool the machine. The inspection system delivers 100% quality control of the full production. This modular concept machine with its compact design offers flexible decoration for premium cosmetic production.
|Output||up to 35 parts/minute|
|Part- Ø||8 – 30 mm (bigger diameters upon request)|
|Part length||20 – 100 mm by using two-side part support (or upon request)|
|Part height||20 – 50 mm by using one-side part support|
|Stamping width||up to 100 mm on 360°|
inner-ø 25.4 mmouter-ø 180 mm
|Conicity half-angle||Max 12°|
